LANG & HEYNE – Friedrich II Remontoir The Lavish Attic Edition 2022
Click, to see the large size. ▶ BIG FOTO
Click, to see the large size. ▶ BIG FOTO
Click, to see the large size. ▶ BIG FOTO
Click, to see the large size. ▶ BIG FOTO
1. The first-ever black enamel dial, made in a different way
The face of the Friedrich II Remontoir is created by a two-part enamel dial. A new state-of-the-art technology gives the possibility to cut massive enamel in slices.
Click, to see the large size. ▶ BIG FOTO
Click, to see the large size. ▶ BIG FOTO
Click, to see the large size. ▶ BIG FOTO
The lancet hands indicate the time extremely accurate and are easy to read even by night thanks to their superluminova filling.
2.The first-ever Remontoir found in small second
Underneath the dial a newly developed Remontoir movement, the calibre Cal. VI-I. is responsible for the accurate display of the time. It is equipped with a complicated mechanism to improve accuracy, the Remontoir.
Click, to see the large size. ▶ BIG FOTO
Click, to see the large size. ▶ BIG FOTO
The Remontoir of Cal. VI-I is located on the escape wheel and is responsible for the jump of the small second hand every second and fulfills its function at least for 24 hours.
Underneath the dial a newly developed Remontoir movement, the caliber LANG & HEYNE Cal. VI-I, is responsible for the accurate display of the time. Through the sapphire glass case back it is obvious, that the main parts of the movement were manufactured of an entire new material – titanium. Commonly used for manufacturing cases, it has found its way into an unusual use.
Click, to see the large size. ▶ BIG FOTO
The use of titanium has presented entirely new challenges to the master watchmakers of LANG & HEYNE. In order to meet the very high demands on the quality of the technology but also on the aesthetics, it was necessary to adapt and modify traditional skills and processes.
Click, to see the large size. ▶ BIG FOTO
Medium-hard titanium of purity grade 2 is used to manufacture the movement plate, gear bridge, lever bridge and balance cock. To create a matte sheen, the graining is achieved by blasting with ceramic beads which, unlike glass beads, do not shatter when they hit the material.
For brass frame parts, the polished chamfers are then pressed on with the smoothing steel. This is not possible with titanium. It has unfavorable friction behavior, which would cause the spinning tool to leave cracks. So here the chamfers have to be polished very laboriously with wood and polishing paste.
The poor behavior under friction also forces a different design for the bearings of all parts that were previously supported in the brass of the plate. Thus, separate bronze bearings are used for the barrel and winding stem.
All other assembly steps can be performed in the same way as with conventional plates, line grindings are easily feasible and hand engravings are also possible. Thus, the balance cock also retains its beautiful classic design. Technically, titanium offers greater strength and corrosion resistance, making it an interesting asset to the movement.
Click, to see the large size. ▶ BIG FOTO
For aesthetic reasons, the otherwise blue annealed screws were replaced with purple ones to match the warm gray of the titanium.
TECHINCAL SPECIFICATIONS
Model: Friedrich II Remontoir The Lavish Attic Edition
🔴 Price : incl. (All excl. VAT) 💰
- Stainless Steel: EUR 59,600
- Rose Gold: EUR 63,900
- White Gold: EUR 66,700
- Platinum: EUR 74,500
Movement
Diameter: 14 ¼ lines (33 mm)
Height: 4.9 mm
Frequency: 18,000 semi-oscillations per hour
Running time: 24/42 h (Remontoir / follow-on)
Finesses: second hand stop mechanism, dead-beat small second, 24 rubies, 1 brilliant
Movement: main plate, trigonal bridge, balance cock and lever bridge are made of titanium
Screws: polished and flame purple manually
Click, to see the large size. ▶ BIG FOTO
Hour and minute indication,
Eccentric second,
Second hand stop mechanism
Case
Stainless steel
Diameter/Height: 39.2 mm / 10.7 mm
Water-resistant: up to 3 bar
Dial
Two-part black enamel dial,
Manufactured by using a completely new technology
Arabic numerals, index 9 and second indexes are in red, rhombi filled with SuperLuminova word “ENAMEL” in the small second
Hands: lancet hands filled with SuperLuminova
Strap
Alligator leather strap with a pin buckle or folding clasp
🔰Limited Edition ✅ Only 9 Pieces
Click, to see the large size. ▶ BIG FOTO
----------------------------------
